Apjohnite

A valid IMA mineral species - grandfathered
This page is currently not sponsored. Click here to sponsor this page.

About ApjohniteHide

This section is currently hidden. Click the show button to view.
Formula:
Mn2+Al2(SO4)4 · 22H2O
Colour:
Colourless, white, light pink, light yellow, light green
Lustre:
Silky
Hardness:
1½ - 2
Specific Gravity:
1.78 - 1.81
Crystal System:
Monoclinic
Name:
Named in honor of James Apjohn (1 September 1796, Ireland - 3 June 1886, Blackrock, Co. Dublin, Ireland), Professor of Chemistry and Mineralogy, Trinity College, Dublin, Ireland. His birthplace is listed from different sources as Granard, Co. Longford and Sunville, Pallasgrean, Co. Limerick. He made contributions in the areas of chemistry, electricity, and mineralogy, and first described this mineral.
Halotrichite Group

At least a partial (and probably a complete ?) series toward Apjohnite exists from Pickeringite and Halotrichite.


Unique IdentifiersHide

This section is currently hidden. Click the show button to view.
Mindat ID:
281
Long-form identifier:
mindat:1:1:281:9

IMA Classification of ApjohniteHide

This section is currently hidden. Click the show button to view.

Classification of ApjohniteHide

This section is currently hidden. Click the show button to view.
7.CB.85

7 : SULFATES (selenates, tellurates, chromates, molybdates, wolframates)
C : Sulfates (selenates, etc.) without additional anions, with H2O
B : With only medium-sized cations
29.7.3.3

29 : HYDRATED ACID AND NORMAL SULFATES
7 : AB2(XO4)4·H2O
25.9.7

25 : Sulphates
9 : Sulphates of Mn

Mineral SymbolsHide

This section is currently hidden. Click the show button to view.
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.

SymbolSourceReference for Standard
ApjIMA–CNMNCWarr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43

Physical Properties of ApjohniteHide

This section is currently hidden. Click the show button to view.
Silky
Transparency:
Transparent, Translucent
Comment:
In aggregates
Colour:
Colourless, white, light pink, light yellow, light green
Streak:
White
Hardness:
1½ - 2 on Mohs scale
Density:
1.78 - 1.81 g/cm3 (Measured)    1.836 g/cm3 (Calculated)

Optical Data of ApjohniteHide

This section is currently hidden. Click the show button to view.
Type:
Biaxial (-)
RI values:
nα = 1.478 nβ = 1.482 nγ = 1.482
Max. Birefringence:
δ = 0.004
Based on recorded range of RI values above.

Interference Colours:
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.

Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.

Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.

Surface Relief:
Moderate
Dispersion:
none
Optical Extinction:
Y = b; Z ∧ c = 30°.

Chemistry of ApjohniteHide

This section is currently hidden. Click the show button to view.
Mindat Formula:
Mn2+Al2(SO4)4 · 22H2O
Element Weights:
Element% weight
O68.351 %
S14.420 %
Mn6.176 %
Al6.067 %
H4.986 %

Calculated from ideal end-member formula.

Crystallography of ApjohniteHide

This section is currently hidden. Click the show button to view.
Crystal System:
Monoclinic
Class (H-M):
2/m - Prismatic
Space Group:
P21/b
Setting:
P21/c
Cell Parameters:
a = 6.19 Å, b = 24.34 Å, c = 21.26 Å
β = 100.28°
Ratio:
a:b:c = 0.254 : 1 : 0.873
Unit Cell V:
3,151.71 ų (Calculated from Unit Cell)
Z:
4
Morphology:
Crystals acicular aggregated into masses and crusts; also asbestiform.

Crystal StructureHide

This section is currently hidden. Click the show button to view.
Load
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Show
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Display Options
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
View
CIF File    Best | x | y | z | a | b | c
Rotation
Stop | Start
Labels
Console Off | On | Grey | Yellow
Data courtesy of the American Mineralogist Crystal Structure Database. Click on an AMCSD ID to view structure
IDSpeciesReferenceLinkYearLocalityPressure (GPa)Temp (K)
0014465ApjohniteMenchetti S, Sabelli C (1976) The halotrichite group: The crystal structure of apjohnite Mineralogical Magazine 40 599-608👁 Image
1976Terlano, Bolzano, Italy0293
CIF Raw Data - click here to close

X-Ray Powder DiffractionHide

This section is currently hidden. Click the show button to view.
Powder Diffraction Data:
d-spacingIntensity
3.515 Å(100)
4.82 Å(90)
3.792 Å(33)
4.33 Å(27b)
3.967 Å(23)
4.13 Å(22)
6.07 Å(20)

Geological EnvironmentHide

This section is currently hidden. Click the show button to view.
Paragenetic Mode(s):
Paragenetic ModeEarliest Age (Ga)
Stage 7: Great Oxidation Event<2.4
45a : [Sulfates, arsenates, selenates, antimonates]
Stage 10b: Anthropogenic minerals<10 Ka
55 : Anthropogenic mine minerals

Type Occurrence of ApjohniteHide

This section is currently hidden. Click the show button to view.

Synonyms of ApjohniteHide

This section is currently hidden. Click the show button to view.

Manganese Alum (in part)

Other Language Names for ApjohniteHide

This section is currently hidden. Click the show button to view.

Relationship of Apjohnite to other SpeciesHide

This section is currently hidden. Click the show button to view.
Other Members of Halotrichite Group:
BíliniteFe2+Fe3+2(SO4)4 · 22H2OMon. 2/m : P21/b
Dietrichite(Zn,Fe2+,Mn2+)Al2(SO4)4 · 22H2OMon. 2/m : P21/b
HalotrichiteFeAl2(SO4)4 · 22H2OMon. 2 : P2
PickeringiteMgAl2(SO4)4 · 22H2OMon. 2/m : P21/b
Redingtonite(Fe2+,Mg,Ni)(Cr,Al)2(SO4)4 · 22H2OMon. 2
Wupatkiite(Co,Mg,Ni)Al2(SO4)4 · 22H2OMon. 2/m : P21/b

Common AssociatesHide

This section is currently hidden. Click the show button to view.
Associated Minerals Based on Photo Data:
1 photo of Apjohnite associated with IlesiteMn2+(SO4) · 4H2O
1 photo of Apjohnite associated with AragoniteCaCO3
1 photo of Apjohnite associated with MagnesiocopiapiteMgFe3+4(SO4)6(OH)2 · 20H2O

Related Minerals - Strunz-mindat GroupingHide

This section is currently hidden. Click the show button to view.
7.CB.SarvodaiteAl2(SO4)3 · 5H2OMon. 2/m : P21/m
7.CB.02VoudourisiteCdSO4 · H2OMon. 2/m : P21/m
7.CB.05SzmikiteMnSO4 · H2OMon. 2/m : B2/b
7.CB.05SzomolnokiteFeSO4 · H2OMon. 2/m : B2/b
7.CB.05CobaltkieseriteCoSO4 · H2OMon. 2/m : B2/b
7.CB.05DwornikiteNi(SO4) · H2OMon. 2/m : B2/b
7.CB.05KieseriteMgSO4 · H2OMon. 2/m : B2/b
7.CB.05Poitevinite(Cu,Fe)SO4 · H2OTric. 1 : P1
7.CB.05GunningiteZnSO4 · H2OMon. 2/m : B2/b
7.CB.07SanderiteMgSO4 · 2H2OOrth. 222 : P212121
7.CB.10BonattiteCuSO4 · 3H2OMon. m : Bb
7.CB.12BelogubiteCuZn(SO4)2 · 10H2OTric. 1 : P1
7.CB.15DrobeciteCdSO4 · 4H2OMon. 2/m : P21/m
7.CB.15Aplowite(Co,Mn,Ni)SO4 · 4H2OMon. 2/m
7.CB.15CranswickiteMgSO4 · 4H2OMon. m : Bb
7.CB.15RozeniteFeSO4 · 4H2OMon. 2/m : P21/b
7.CB.15StarkeyiteMgSO4 · 4H2OMon. 2/m : P21/b
7.CB.15IlesiteMn2+(SO4) · 4H2OMon. 2/m
7.CB.15BoyleiteZnSO4 · 4H2OMon. 2/m : P21/b
7.CB.20SiderotilFeSO4 · 5H2OTric.
7.CB.20JôkokuiteMnSO4 · 5H2OTric. 1 : P1
7.CB.20PentahydriteMgSO4 · 5H2OTric. 1 : P1
7.CB.20ChalcanthiteCuSO4 · 5H2OTric. 1 : P1
7.CB.25ChvaleticeiteMn(SO4) · 6H2OMon. 2/m : B2/b
7.CB.25NickelhexahydriteNi(SO4) · 6H2OMon. 2/m : B2/b
7.CB.25HexahydriteMgSO4 · 6H2OMon. 2/m : P2/m
7.CB.25BianchiteZn(SO4) · 6H2OMon. 2/m : P2/m
7.CB.25MoorhouseiteCo(SO4) · 6H2OMon. 2/m : B2/b
7.CB.25FerrohexahydriteFeSO4 · 6H2OMon. 2/m : B2/b
7.CB.30RetgersiteNiSO4 · 6H2OTet. 422 : P41212
7.CB.35Zincmelanterite(Zn,Cu,Fe)SO4 · 7H2OMon. 2/m : P21/b
7.CB.35MelanteriteFe2+(H2O)6SO4 · H2OMon. 2/m : P21/b
7.CB.35Alpersite(Mg,Cu)(SO4) · 7H2OMon. 2/m : P21/b
7.CB.35BieberiteCoSO4 · 7H2OMon. 2/m : P2/m
7.CB.35BoothiteCuSO4 · 7H2OMon. 2/m : P21/b
7.CB.35MallarditeMnSO4 · 7H2OMon. 2/m : P2/m
7.CB.40EpsomiteMgSO4 · 7H2OOrth. 222 : P212121
7.CB.40GoslariteZnSO4 · 7H2OOrth. 222 : P212121
7.CB.40MorenositeNiSO4 · 7H2OOrth. 222 : P212121
7.CB.45Meta-alunogenAl2(SO4)3 · 12H2OOrth.
7.CB.45AlunogenAl2(SO4)3 · 17H2OTric. 1 : P1
7.CB.50AluminocoquimbiteAl2Fe2(SO4)6(H2O)12 · 6H2OTrig. 3m(32/m) : P31c
7.CB.50Lazaridisite3CdSO4 · 8H2OMon. 2/m : B2/b
7.CB.52PararaisaiteCuMg[Te6+O4(OH)2] · 6H2OMon. 2/m : P21/b
7.CB.55ParacoquimbiteFe4(SO4)6(H2O)12 · 6H2OTrig. 3 : R3
7.CB.55Rhomboclase(H5O2)Fe3+(SO4)2 · 2H2OOrth. mmm(2/m2/m2/m) : Pnma
7.CB.55RaisaiteCuMg[Te6+O4(OH)2] · 6H2OMon. 2/m : B2/b
7.CB.55CoquimbiteAlFe3(SO4)6(H2O)12 · 6H2OTrig. 3m(32/m) : P31c
7.CB.57'Caichengyunite'Fe2+3Al2(SO4)6 · 30H2OMon.
7.CB.60KorneliteFe2(SO4)3 · 7H2OMon. 2/m : P21/m
7.CB.65QuenstedtiteFe2(SO4)3 · 11H2OTric. 1 : P1
7.CB.70LauseniteFe2(SO4)3 · 5H2OMon. 2/m : P21/m
7.CB.75RömeriteFe2+Fe3+2(SO4)4 · 14H2OTric. 1 : P1
7.CB.75LishizheniteZnFe2(SO4)4 · 14H2OTric. 1 : P1
7.CB.80RansomiteCuFe2(SO4)4 · 6H2OMon. 2/m : P21/b
7.CB.85Dietrichite(Zn,Fe2+,Mn2+)Al2(SO4)4 · 22H2OMon. 2/m : P21/b
7.CB.85HalotrichiteFeAl2(SO4)4 · 22H2OMon. 2 : P2
7.CB.85Redingtonite(Fe2+,Mg,Ni)(Cr,Al)2(SO4)4 · 22H2OMon. 2
7.CB.85PickeringiteMgAl2(SO4)4 · 22H2OMon. 2/m : P21/b
7.CB.85BíliniteFe2+Fe3+2(SO4)4 · 22H2OMon. 2/m : P21/b
7.CB.85Wupatkiite(Co,Mg,Ni)Al2(SO4)4 · 22H2OMon. 2/m : P21/b
7.CB.90MeridianiiteMgSO4 · 11H2OTric. 1 : P1

Other InformationHide

This section is currently hidden. Click the show button to view.
Notes:
Soluble in water.
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.

Internet Links for ApjohniteHide

This section is currently hidden. Click the show button to view.

References for ApjohniteHide

This section is currently hidden. Click the show button to view.
Reference List:

Localities for ApjohniteHide

This section is currently hidden. Click the show button to view.

Showing 38 localities.

This map shows a selection of localities that have latitude and longitude coordinates recorded. Click on the 👁 Image
symbol to view information about a locality. The 👁 Image
symbol next to localities in the list can be used to jump to that position on the map.

Locality ListHide

This section is currently hidden. Click the show button to view.
👁 Image
- This locality has map coordinates listed.
👁 Image
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence. ? - Indicates mineral may be doubtful at this locality. 👁 Image
- Good crystals or important locality for species.
👁 Image
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species. (FRL) - First Recorded Locality for everything else (eg varieties). Struck out - Mineral was erroneously reported from this locality. Faded * - Never found at this locality but inferred to have existed at some point in the past (e.g. from pseudomorphs).

All localities listed without proper references should be considered as questionable.
Bulgaria
  • Plovdiv Province
    • Rodopi Municipality
Atanassova et al. (2009)
Chile
  • Tarapacá
    • Tamarugal Province
Peter G. Seroka collection
Costa Rica
  • Alajuela Province
    • Sarchí Canton
Rodríguez et al. (2017)
  • Cartago Province
    • Oreamuno Canton
      • Irazú Volcano
Ulloa et al. (2018)
Czech Republic
  • Karlovy Vary Region
    • Karlovy Vary District
Lapis 2002 (7/8)
  • Pardubice Region
    • Pardubice District
Greece
  • Attica
    • East Attica
      • Lavreotiki
Rieck et al. (2020)
        • Plaka
          • Plaka Mines
Rieck et al. (2020)
Italy
  • Trentino-Alto Adige/Südtirol
    • South Tyrol
      • Überetsch-Unterland (Oltradige-Bassa Atesina)
Locke et al. (2007)
Exel (1987)
Mozambique (TL)
  • Maputo Province
    • Maputo
Palache et al. (1951) +1 other reference
Portugal
  • Aveiro
    • Albergaria-a-Velha
      • Branca
Marques de Sá et al. (2010)
Romania
  • Alba County
    • Roșia Montană
Onac (2003)
  • Caraş-Severin County
    • Băile Herculane
B. Onac et al (2009, July)
  • Hunedoara County
    • Certeju de Sus
      • Bocşa Mare
Apopei et al. (2014)
    • Domogled - Cernei Valley National Park
Onac (2009)
  • Maramureș County
    • Băiuț
Ł. Kruszewski & M. Cegiełka PXRD data +2 other references
Russia
  • Kamchatka Krai
    • Yelizovsky District
Okrugin (2004)
Bortnikova et al. (2009, February)
Bortnikova et al. (2009, February)
  • Sakha
    • Verkhoyansk Fold Belt
      • Verkhoyansk Silver Province
        • Deputatsky ore cluster
Zhdanov Yu.Ya. (1998)
Senegal
  • Ziguinchor Region
Montoroi (1995)
Slovakia
  • Košice Region
    • Gelnica District
Kokta (1939) +2 other references
  • Prešov Region
    • Prešov District
      • Červenica
        • Dubník
Koděra (1986)
Spain
  • Andalusia
    • Huelva
      • Alosno
        • Tharsis
Valente et al. (2013)
  • Galicia
    • Lugo
      • Quiroga
        • Quiroga
Carlos J. Rodríguez collection
  • Murcia
    • La Unión
Tony Nikischer and Luis Menezes
    • Mazarrón
      • San Cristóbal Hill
USA
  • Colorado
    • Mineral County
Eckel et al. (1997)
  • Nevada
    • Nye County
      • Cactus Range
        • Cactus Springs Mining District
Castor et al. (2004)
          • Urania Peak
Castor et al. (2004)
    • Washoe County
      • Wedekind Mining District
Castor et al. (2004)
  • New Mexico
    • Santa Fe County
Northrop et al. (1996)
        • Golden
          • Ortiz Project
Northrop et al. (1996)
  • Pennsylvania
    • Columbia County
Scientific study done by Matt Livingood
  • Tennessee
    • Monroe County
      • Tellico Plains
Paris (2011)
    • Sevier County
Palache et al. (1951) +2 other references
  • Utah
    • Salt Lake County
Bullock (1981)
Quick NavTopAbout ApjohniteUnique IdentifiersIMA Classification Classification Mineral SymbolsPhysical Properties Optical Data Chemistry Crystallography Crystal StructureX-Ray Powder DiffractionGeological EnvironmentType Occurrence SynonymsOther LanguagesRelationshipsCommon AssociatesStrunz-MindatOther InformationInternet Links References Localities Locality List
Mindat.org® is an outreach project of the Hudson Institute of Mineralogy, a 501(c)(3) not-for-profit organization. Mindat® and mindat.org® are registered trademarks of the Hudson Institute of Mineralogy.
Copyright © mindat.org and the Hudson Institute of Mineralogy 1993-2026, except where stated. Most political location boundaries are © OpenStreetMap contributors. Mindat.org relies on the contributions of thousands of members and supporters. Founded in 2000 by Jolyon Ralph and Ida Chau.
To cite: Ralph, J., Von Bargen, D., Martynov, P., Zhang, J., Que, X., Prabhu, A., Morrison, S. M., Li, W., Chen, W., & Ma, X. (2025). Mindat.org: The open access mineralogy database to accelerate data-intensive geoscience research. American Mineralogist, 110(6), 833–844. doi:10.2138/am-2024-9486.
Privacy Policy - Terms & Conditions - Contact Us / DMCA issues - Report a bug/vulnerability Current server date and time: April 4, 2026 14:25:27 Page updated: March 8, 2026 18:42:20
Go to top of page
